| ，Bulb type and characteristics BA9S-11〜28mm-1.2W
max. |
 |
Type |
Voltage |
Lamp color |
Lens colsr |
| TS9-1R |
110VAC |
red |
Red lamps for use with red, orange, white lens.
Green lamps for use with green, blue lens.
|
| TS9-1G |
green |
| TS9-2R |
220VAC |
red |
| TS9-2G |
green |
| TS9-3R |
380VAC |
red |
| TS9-3G |
green |
| TS9-4R |
440VAC |
red |
| TS9-4G |
green |
|
 |
Type |
Voltage |
TS9-5 |
6V |
TS9-6 |
18V |
TS9-7 |
24V |
TS9-8 |
30V |
TS9-9 |
12V |
|
|
| ，Model designation |
 |
Designation |
Signal |
Description |
1.Mounting Hole
|
T2 |
Φ 22mm/
Φ
25mm |
T3 |
Φ 30mm |
2.Type |
IF |
Flat Head |
IL |
Long Head |
IM |
Mushroom Head |
IA |
Long Head (Alternate) |
IB |
Mushroom Head (Alternate) |
IK |
Push-Lock |
IT |
Twin-Touch |
3.Shape |
R |
Round |
S |
Square |
L |
Rectangular |
4.Voltage |
1 |
110VAC (Neon Bulb) |
2 |
220 ＾ ( ＾ ) |
3 |
380 ＾ ( ＾ ) |
4 |
440 ＾ ( ＾ ) |
5 |
6V ＾ (Filament Bulb) |
6 |
18V ＾ ( ＾ ) |
7 |
24V ＾ ( ＾ ) |
8 |
30V ＾ ( ＾ ) |
9 |
12V ＾ ( ＾ ) |
5.Lens Color |
R |
Red |
G |
Green |
O |
Orange |
W |
White |
BL |
Blue |
6.No. of Contact |
1-3 |
1-3 |
7.Type of |
A |
1a |
B |
1b |
C |
1a1b |
|
| 1. The mounting holes of square series are Φ22mm/
Φ
25mm available. |
2. Twin-Touch illuminated push button is available with rectangular shape, various
colors, and transparent.
|
|
