Designation |
Signal |
Description |
| 1.Type |
TMS
TMR
TES
TEB
TEL
TEW |
Open Type
Reversing Type
Enclosed Type
Enclosed with pushbutton
enclosed with indicator
Enclosed with rainproof
(IEC144 Ip65) |
| 2.Model |
11
16
21
30
35
40 |
12A (Rated
capacity 16Abased on AC3 3PH,220VAC)
16A
24A
30A
35A
44A |
3.Auxiliary
Contacts |
（none)
A
B |
1a1b,2a2b(For TMS50,60)
1a
1b |
| |
|
50Hz |
60Hz |
| 4.Coil voltage |
1
2
3
4
5
6
7
8
9
a
b
c
|
100VAC
200~220VAC
346~380VAC
380~415VAC
110~127VAC
220~240VAC
24VAC
48VAC
415~440VAC
220VAC
500VAC
32VAC |
100~110VAC
220~240VAC
380VAC
400~440VAC
115~127VAC
230~240VAC
24~26VAC
48~52VAC
460~500VAC
240VAC
550VAC
32VAC
|
5.Number of
Heaters |
2
3
P |
2Heaters
3Heaters
Phase-Failure(3 Heaters) |
6.Heater
Setting
Range |
See Thermal overload relays |
